Frameless, brushless, inner-rotor servo motor

IR16-652057

Product details

The IR Series frameless motors are axially compact brushless DC motors with a conventional internal rotor design. They feature a relatively high slot fill resulting in high torque density

We offer two standard sizes, based on stator diameter, the IR9 and IR16 with a range of standard windings and stack lengths. If these standard solutions don’t meet your requirements we will work with you to develop a specification perfectly optimised for your application

PMW’s maximum slot fill manufacturing techniques and access to powerful grades of magnets means that we can optimise your motor to 94% efficiency at your load point. Parameters for motor optimisation are speed, voltage, torque, efficiency, cogging torque and thermal performance

Rated

  • Torque 11.54 Nm
  • Power 580 W
  • Speed 480 RPM
  • Current 1.5 A rms

Peak

  • Torque - - - Nm
  • Power - - - W
  • Voltage 320 V
  • Max Speed - - - RPM

Power rating scale
